Case histories

Alyeska Pipeline replaced tag-line and tethered ADCP float surveys at Trans-Alaska Pipeline river crossings with a CEE-USV™ and RTK CEESCOPE-LITE™ with integrated Trimble GNSS. Surveyors start almost on arrival, work in high flow at over 4 m/s, and get far denser data, including coverage up and downstream of the pipe.

Alyeska Pipeline replaced tag-line and tethered ADCP float surveys at Trans-Alaska Pipeline river crossings with a CEE-USV™ and RTK CEESCOPE-LITE™ with integrated Trimble GNSS. Surveyors start almost on arrival, work in high flow at over 4 m/s, and get far denser data, including coverage up and downstream of the pipe.

BayLand Consultants & Designers chose the CEE ECHO™ with HYPACK for shallow water surveys in the Chesapeake Bay. The compact system improved survey craft flexibility and mobilization time, and training in full water column echograms lets BayLand more quickly identify and remove submerged aquatic vegetation signals.

BayLand Consultants & Designers chose the CEE ECHO™ with HYPACK for shallow water surveys in the Chesapeake Bay. The compact system improved survey craft flexibility and mobilization time, and training in full water column echograms lets BayLand more quickly identify and remove submerged aquatic vegetation signals.

GIS Surveyors surveyed the 8.2 acre Lake Eleanor reservoir from a kayak with a CEE-LINE™, Trimble R10 and TSC3, with no extra mobilization or setup time. Data went to Civil 3D for contours and a volume calculation, and the client was very happy with the results.

GIS Surveyors surveyed the 8.2 acre Lake Eleanor reservoir from a kayak with a CEE-LINE™, Trimble R10 and TSC3, with no extra mobilization or setup time. Data went to Civil 3D for contours and a volume calculation, and the client was very happy with the results.

Mare Island Dry Dock fitted its new survey boat with an RTK CEESCOPE™ and HYPACK® to monitor sediment around its dry docks in-house. With California Real Time Network RTK corrections it gets a few-centimetre horizontal accuracy and survey results in one day, at an accuracy at least as good as paid third-party single beam surveys.

Mare Island Dry Dock fitted its new survey boat with an RTK CEESCOPE™ and HYPACK® to monitor sediment around its dry docks in-house. With California Real Time Network RTK corrections it gets a few-centimetre horizontal accuracy and survey results in one day, at an accuracy at least as good as paid third-party single beam surveys.

USGS scientists surveyed nearly 900 km of river for a groundwater study, towing a resistivity array with a CEESCOPE™ then a CEE ECHO™ and Hemisphere ATLAS L-Band GNSS. One acquisition process gave water column height, position and 20 cm PPP elevation with no base station.

USGS scientists surveyed nearly 900 km of river for a groundwater study, towing a resistivity array with a CEESCOPE™ then a CEE ECHO™ and Hemisphere ATLAS L-Band GNSS. One acquisition process gave water column height, position and 20 cm PPP elevation with no base station.

WaterCube ran a successful reconnaissance survey of the Silver River, Florida, where vegetation covers almost the whole bottom. The CEE ECHO™ 200 kHz channel mapped the top of the canopy and post processed 33 kHz data revealed the true bottom, giving plant height and coverage.

WaterCube ran a successful reconnaissance survey of the Silver River, Florida, where vegetation covers almost the whole bottom. The CEE ECHO™ 200 kHz channel mapped the top of the canopy and post processed 33 kHz data revealed the true bottom, giving plant height and coverage.

Hughes & Associates, an Alaska hydrographic surveyor, replaced three older echo sounders with one CEE ECHO™. The data is cleaner, the sounder tracks the sea floor more consistently, and its compact size and internal battery suit flying out to remote sites on small aircraft.

Hughes & Associates, an Alaska hydrographic surveyor, replaced three older echo sounders with one CEE ECHO™. The data is cleaner, the sounder tracks the sea floor more consistently, and its compact size and internal battery suit flying out to remote sites on small aircraft.

At the Ray copper mine in Arizona the CEE-USV™ made the first ever bathymetric survey of the Elder Gulch tailings impoundment, and surveyed corrosive acid leach ponds with no one on the water. Hydromagic gave the mine its water volumes within an hour of finishing the surveys.

At the Ray copper mine in Arizona the CEE-USV™ made the first ever bathymetric survey of the Elder Gulch tailings impoundment, and surveyed corrosive acid leach ponds with no one on the water. Hydromagic gave the mine its water volumes within an hour of finishing the surveys.

Coastal Frontiers surveyed a small system of extremely shallow, soft-mud lagoons in San Diego with a CEE-USV™, impossible for a manned boat. With a 10 cm (4″) blanking distance and 10 cm draft it sounded almost the whole lagoon, and the process was practically identical to a manned boat survey.

Coastal Frontiers surveyed a small system of extremely shallow, soft-mud lagoons in San Diego with a CEE-USV™, impossible for a manned boat. With a 10 cm (4″) blanking distance and 10 cm draft it sounded almost the whole lagoon, and the process was practically identical to a manned boat survey.

Bhutanese surveyors, guided by IAMHYDRO GmbH, surveyed rivers for hydropower impact evaluation from kayaks with an RTK CEESCOPE™. Its autonomous logging and shallow water bottom tracking coped with aerated white water, and the bathymetry was merged with land and drone survey data into a 3D model of the rivers.

Bhutanese surveyors, guided by IAMHYDRO GmbH, surveyed rivers for hydropower impact evaluation from kayaks with an RTK CEESCOPE™. Its autonomous logging and shallow water bottom tracking coped with aerated white water, and the bathymetry was merged with land and drone survey data into a 3D model of the rivers.
